|Application Field:||Car Doors||Cooperation Case:||SAIC Motor|
|Performance:||Excellent Adhesion||Main Ingredients:||Totally Enclosed Multi-isocyanates|
Car doors ED black coating,
anti shrinkage ED black coating,
Car doors cathodic electrodeposition coating
Automobile door industry electrophoretic coating
HLS-1701BLB/HLS-1701B Black Cationic Epoxy Electrocoat for auto is a new generation electrophoretic coating researched and developed by HLS Paint (Shanghai) Co., Ltd.
It represents modern technology of cathodic electrophoretic coating that is environment-friendly with high property and low cost. Such coating does not contain heavy metal like lead, tin, cadmium and mercury etc. It is a two-component, water-dispersed resin,meanwhile, it took in features of previous products, and can adapt galvanized steel sheet perfectly, almost can be applied to foundation coating of all metal, such as: cold and hot rolled steel sheet, galvanized steel sheet, aluminum products and stainless steel sheet etc.
This product features shown below:
The bath has strong anti-shrinkage and anti-pollution ability.
Strong anti-corrosion properties, good salt spray resistance workpiece edge.
The main component Matrix resin:
|Neutralizing agent: organic acid||Solvent: alcohol ether|
Filling tank proportion and method
⑴ Ripening conditions
Sample quantity: 3000～5000g
Container: 5L (Diameter 16cm)
Tank temperature:28-30 ℃
Mixed conditions: impeller diameter 8cm (speed 200rpm)
Product film performance
|Appearance||Normal / abnormal||Normal||Ocular estimate|
|Cup drawing||mm ,≥||6||GB/T 9753|
|Water resistance||h,(23±2)℃,≥||240||GB/T 1733|
|Acid resistance||h,(50g/L H2SO4),≥||72||GB/T 9274|
|Alkali resistance||h,(50g/L NaOH),≥||48||GB/T 9274|
|*Salt spray resistance||h,(film thickness ≥ 20μm) ,≥||1000||GB/T 1771|
* Note: The substrate use the Bonder standard phosphating steel panel, crossed out unidirectional expansion eclipse ≤ 2mm.
Storage, packaging and transportation
This product is a water-borne industrial coatings, non-hazardous, non-inflammable and explosive products; transportation to prevent direct sunlight, avoid freezing (>5℃ ); Packaging for 50/60/200L Plastic barrel; in the transport and storage of drums should be maintained clean, avoid charging the dirt brought in on drums during filling tank, again checked and confirmed that the quality of products, including paste resin,emulsions and additives should be indoor storage, good ventilation, dry, protect against freezing and overheating, the storage temperature should be controlled at 5～35℃, products from the date of production, over shelf, experimentation is required to determine whether can continue to use.
