Product Details:
Place of Origin: Shanghai China (Mainland)
Brand Name: HAOLISEN
Certification: IATF16949 , ISO9001
Model Number: HLS-5701LB/HLS-5750
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 50kg、60 kg、200kg、1000kg packaging barrels
Delivery Time: 30-60 Days
Supply Ability: 200 Tons Per Day

Electrocoating Electrophoretic Painting With Polyurethane Modified Epoxy Resin

Color: Grey Shelf Life: 1 Year
Application Field: High Anticorrosive Products Performance: High Anticorrosive
Cooperation Case: ASIASTAR,KING LONG Main Ingredients: Polyurethane Modified Epoxy Resin
High Light:

e coat paint


epd coating

High anticorrosive performance grey electrophoretic coating​
Product Introduction :

HLS-5701LB/HLS-5750 Gray Cationic Epoxy Electrocoat for auto is the 7th generation electrophoretic coating researched and developed by HLS Paint (Shanghai) Co., Ltd. in cooperation with Germany HS International Chemical Industry Group.
It represents modern technology of cathodic electrophoretic coating that is environment-friendly with high property and low cost. Such coating does not contain heavy metal like lead, tin, cadmium and mercury etc. It is a two-component, water-dispersed resin,meanwhile, it took in features of previous products, and can adapt galvanized steel sheet perfectly, almost can be applied to foundation coating of all metal,
such as: cold and hot rolled steel sheet, galvanized steel sheet, aluminum products, zinc-aluminum alloy sheet and stainless steel sheet etc.


This product features shown below:


High throwing power, internal and external uniformity


The appearance of the coating is flat, delicate, smooth

Coating fullness of good, better substrate hiding  Suitable for automotive, cab, car, bus, truck, trailer and so on


The main component :

1,Curing agent: totally enclosed multi-isocyanates

2,Solvent: alcohol ether

3,Pigment: Titanium pigment, carbon black, kaolin, antirust pigment

Product film performance ​:


Project   Indicator Test standard
Appearance Normal / Abnormal Normal Ocular estimate
Hardness 2H GB/T 6739
Cup drawing mm, 6 GB/T 9753
Adhesion level 0 GB/T 9286
Flexibility mm 1 GB/T 1731
Impact Kg.cm 50 GB/T 1732
Gloss 60° 50-80 GB/T 9754
Water resistance h,(23±2)℃   240 GB/T 1733
Acid resistance h(0.05N H2SO4)  72 GB/T 9274
Alkali resistance h(0.1N NaOH 72 GB/T 9274
*Salt spray resistance film thickness 20μm 1000

GB/T 1771

Stone strike resistance level  3.0 Q/DFLCM 5466

* Note: The substrate use the Bonder standard phosphating steel panel, crossed out unidirectional expansion eclipse ≤ 2mm.

Storage, packaging and transportation:


This product is a water-borne industrial coatings, non-hazardous, non-inflammable and explosive products; transportation to prevent direct sunlight, avoid freezing (>5℃ ); Packaging for 50/60/200L Plastic barrel; in the transport and storage of drums should be maintained clean, avoid charging the dirt brought in on drums during filling tank, again checked and confirmed that the quality of products, including paste resin, emulsions and additives should be indoor storage, good ventilation, dry, protect against freezing and overheating, the storage temperature should be controlled at 5~35℃, products from the date of production, over shelf, experimentation is required to determine whether can continue to use.


Specification statement :


This manual contains information and recommendations are based on our current knowledge and experience, accurate to the date of publication so far. It cannot be used as a guarantee or commitment, in any case, responsibility for users to decide on the use of this product is intended availability. We remain in the process or new development within the scope of the right to change product specifications. Because we cannot control the construction conditions, hope through customers own experiments to determine satisfaction with the final results.

If you want to learn more about HLS coating products, please contact Sales Department of Shanghai HLS now
