|Application Field:||Tractor||Performance:||High Hardness|
|Main Ingredients:||Carbon Black, Kaolin||Cooperation Case:||LION CHINA|
cationic epoxy electrocoat,
Solution for tractor electrophoresis paint
Product Introduction :
HS-6060LB/HS-2668G Gray Cationic Epoxy Electrocoat for auto is a new generation electrophoretic coating researched and developed by HLS Paint (Shanghai) Co., Ltd.
It represents modern technology of cathodic electrophoretic coating that is environment-friendly with high property and low cost. Such coating does not contain heavy metal like lead, tin, cadmium and mercury etc. It is a two-component, water-dispersed resin,meanwhile, it took in features of previous products, and can adapt galvanized steel sheet perfectly, almost can be applied to foundation coating of all metal
such as: cold and hot rolled steel sheet, galvanized steel sheet, aluminum products, zinc-aluminum alloy sheet and stainless steel sheet etc.
Main ingredients :
1,Neutralizing agent: organic acid
2,Matrix resin: Acrylic modified epoxy resin
3,Additives: surface active agent, prevent shrinkage cavity agent
Product film performance:
|Appearance||Normal / abnormal||Normal||Ocular estimate|
|Cup drawing||mm ,≥||6||GB/T 9753|
|Water resistance||h,(23±2)℃,≥||240||GB/T 1733|
|Acid resistance||h,(50g/L H2SO4),≥||72||GB/T 9274|
|Alkali resistance||h,(50g/L NaOH),≥||48||GB/T 9274|
|*Salt spray resistance||h,(film thickness ≥ 20μm) ,≥||1000||GB/T 1771|
* Note: The substrate use the Bonder standard phosphating steel panel, crossed out unidirectional expansion eclipse ≤ 2mm.
Storage, packaging and transportation:
This product is a water-borne industrial coatings, non-hazardous, non-inflammable and explosive products; transportation to prevent direct sunlight, avoid freezing (>5℃ ); Packaging for 50/60/200L Plastic barrel; in the transport and storage of drums should be maintained clean, avoid charging the dirt brought in on drums during filling tank, again checked and confirmed that the quality of products, including paste resin, emulsions and additives should be indoor storage, good ventilation, dry, protect against freezing and overheating, the storage temperature should be controlled at 5～35℃, products from the date of production, over shelf, experimentation is required to determine whether can continue to use.
