Non Toxic E Coat Car Coating With Carbon Black / Kaolin / Anti Rust Pigment Pigment

China Non Toxic E Coat Car Coating With Carbon Black / Kaolin / Anti Rust Pigment Pigment supplier

Large Image :  Non Toxic E Coat Car Coating With Carbon Black / Kaolin / Anti Rust Pigment Pigment

Product Details:

Place of Origin: Shanghai China (Mainland)
Brand Name: HAOLISEN
Certification: IATF16949 , ISO9001
Model Number: HL-1607LB/HL-1530G

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 50kg、60 kg、200kg、1000kg packaging barrels
Delivery Time: 30-60 Days
Supply Ability: 200 Tons Per Day
Contact Now
Detailed Product Description
Application Field: Electric Vehicle Frame Main Ingredients: Surface Active Agent, Prevent Shrinkage Cavity Agent
Cooperation Case: Yadea Performance: Better Substrate Hiding

Solution for the electric vehicle frame electrophoresis paint





Product Introduction:



HL-1607LB/HL-1530G Black Cationic Epoxy Electrocoat for auto is a new generation electrophoretic coating researched and developed by HLS Paint (Shanghai) Co., Ltd.



It represents modern technology of cathodic electrophoretic coatingthat isenvironment-friendly withhigh propertyandlow cost. Such coatingdoesnot contain heavy metal like lead, tin, cadmium and mercury etc. It is a two-component, water-dispersed resin,meanwhile, it took in features of previous products, andcan adapt galvanized steel sheet perfectly,almost canbe applied to foundation coating of all metal.



suchas: coldandhotrolledsteelsheet,galvanizedsteel sheetandstainless steelsheetetc.



This product features shown below:



The appearance of the coating is flat, delicate, smooth, uniform high gloss. 
Excellent leveling coating,good bonding for ceand compatibility with plastic powder.





The main component Matrix resin:



1, Neutralizing agent: organic acid



2, Solvent: alcohol ether



3, Pigment: carbon black, kaolin, antirust pigment



4, Curing agent: Fully enclosed multi isocyanate






Bath on site management project



Good bath data and coating quality, from the strict parameters management and maintenance of equipment, production line according to its own reality time situation, can have different management project and specifications, recommend the construction parameters see the table below for reference:



Classification Project Control Data Testing frequency
New bath Anolyte
Electrophoresis tank Ratio 1:4 --
Ripening time 24-48 --
Solid ( 120 ℃ /1h ,% ) 14±4 -- once a day
PH 5.7-6.0 2.0-3.5 once a day
Conductivity ( μs/cm ) 1200±400 1500±700 once a day
P/B 0.08-0.15 once a week
L panel Smooth horizontal plane and vertical plane without obvious differences once a week
Solvent content (%) 0.5-1.8 once a week
Liquid level Fall head (cm ) 10-15 once a day
ED voltage( V ) 0-300 once a day
Break voltage ( V ) ≥320 once a week
Bath temperature ( ℃ ) 28-35 once a day
ED time( S ) 60-180 once a day
UF - 1 Tank Solid content (%) ≤2.0 once a day
UF - 2 Tank Solid content (%) ≤0.8 once a day
Baking furnace Provisions furnace temperature( ℃ ) 180-190    once a day
Curing conditions Drying temperature
(175-185)℃×(20-30)min (With content holding time)
once a day





Construction equipment



Cathodic electrophoretic coating construction in the electrophoresis tank, so need to have the following equipment: 

Electrophoresis tank 

Circulation devices (including filter, fill the paint device) 

DI water equipment 

DC power supply and the power supply unit 

Anode box (tube) and circulation device 

Ultrafiltration device 

Cleaning devices 

Heat exchanging equipment 

Curing device



Customer production site​ :



Non Toxic E Coat Car Coating With Carbon Black / Kaolin / Anti Rust Pigment Pigment
