Cationic Epoxy Electrodeposition Coating High Conductivity For Mixer Truck

Cationic Epoxy Electrodeposition Coating High Conductivity For Mixer Truck
Cationic Epoxy Electrodeposition Coating High Conductivity For Mixer Truck

Large Image :  Cationic Epoxy Electrodeposition Coating High Conductivity For Mixer Truck

Product Details:

Place of Origin: Shanghai China (Mainland)
Brand Name: HAOLISEN
Certification: IATF16949 , ISO9001
Model Number: HLS-1701BLB/HLS-1701B

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 50kg、60 kg、200kg、1000kg packaging barrels
Delivery Time: 30-60 Days
Supply Ability: 200 Tons Per Day
Detailed Product Description
Application Field: Mixer Truck Cooperation Case: XG
Performance: Better Film Main Ingredients: Alcohol Ether ; Carbon Black
High Light:

edp coating


electro coating

Solution for electrophoretic paint of Mixer Truck


Product Introduction:



HLS-1701BLB/HLS-1701B Black Cationic Epoxy Electrocoat for auto is a new generation electrophoretic coating researched and developed by HLS Paint (Shanghai) Co., Ltd.



It represents modern technology of cathodic electrophoretic coating that is environment-friendly with high property and low cost. Such coating does not contain heavy metal like lead, tin, cadmium and mercury etc. It is a two-component, water-dispersed resin,meanwhile, it took in features of previous products, and can adapt galvanized steel sheet perfectly, almost can be applied to foundation coating of all metal



such as: cold and hot rolled steel sheet, galvanized steel sheet, aluminum products and stainless steel sheet etc.



This product features shown below:



Coating fullness of good, better substrate hiding .


Strong anti-corrosion properties, good salt spray resistance workpiece edge.




Ideal for high demand for salt spray industry, such as pipe trench, auto chassis parts, castings



Good stability of bath can adaptable for a longer updating cycle.


The main component Matrix resin :


Matrix resin: polyurethane modified epoxy resin


Curing agent: totally enclosed multi-isocyanates


Neutralizing agent: organic acid


Solvent: alcohol ether


Additives: surface active agent, prevent shrinkage cavity agent


Pigment: Titanium pigment, carbon black, kaolin, antirust pigment


Product film performance :


Project Indicator Test standard
Appearance Normal / abnormal Normal Ocular estimate
Hardness 2H GB/T 6739
Cup drawing mm ,≥ 6 GB/T 9753
Adhesion Level 0 GB/T 9286
Flexibility mm 1 GB/T 1731
Impact kg·cm 50 GB/T 1732
Gloss 60 50-80 GB/T 9754
Water resistance h,(23±2)℃,≥ 240 GB/T 1733
Acid resistance h,(50g/L H2SO4),≥ 72 GB/T 9274
Alkali resistance h,(50g/L NaOH),≥ 48 GB/T 9274
*Salt spray resistanc​e h,(film thickness ≥ 20μm) ,≥ 1000 GB/T 1771

* Note: The substrate use the Bonder standard phosphating steel panel, crossed out unidirectional expansion eclipse ≤ 2mm.


Storage, packaging and transportation :


This product is a water-borne industrial coatings, non-hazardous, non-inflammable and explosive products; transportation to prevent direct sunlight, avoid freezing (>5℃ ); Packaging for 50/60/200L Plastic barrel; in the transport and storage of drums should be maintained clean, avoid charging the dirt brought in on drums during filling tank, again checked and confirmed that the quality of products, including paste resin, emulsions and additives should be indoor storage, good ventilation, dry, protect against freezing and overheating, the storage temperature should be controlled at 5~35℃, products from the date of production, over shelf, experimentation is required to determine whether can continue to use.

If you want to learn more about HLS coating products, please contact Sales Department of Shanghai HLS now
