Domestic Air Conditioning Cathodic Electrodeposition Coating Process No Stratified State

China Domestic Air Conditioning Cathodic Electrodeposition Coating Process No Stratified State supplier

Large Image :  Domestic Air Conditioning Cathodic Electrodeposition Coating Process No Stratified State

Product Details:

Place of Origin: Shanghai China (Mainland)
Brand Name: HAOLISEN
Certification: IATF16949 , ISO9001
Model Number: HS-5400LB/HS-5400

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 50kg、60 kg、200kg、1000kg packaging barrels
Delivery Time: 30-60 Days
Supply Ability: 200 Tons Per Day
Contact Now
Detailed Product Description
Main Ingredients: Antirust Pigment Application Field: Air Conditioning
Performance: Good Film Cooperation Case: AUX,Chunlan

Special domestic air conditioning white electrophoresis paint



Product Introduction :



HS-5400LB/HS-5400 White epoxy acrylic cathodic electrophoretic coating for auto is the 8th generation electrophoretic coating researched and developed by HLS Paint (Shanghai) Co., Ltd. in cooperation with Germany HS International Chemical Industry Group,and get the national invention patent and the Shanghai science and technology commission of high-tech transformation project.It represents modern technology of cathodic electrophoretic coating that is environment-friendly with high property and low cost. Such coating does not contain heavy metal like lead, tin, cadmium and mercury etc. It is a two-component, water-dispersed resin. The coating that does not contain tin element meet the latest environ-mental regulations of European Union, North America, Japan and other requirements in advance, which is the inevitable trend of future environ-mental coating and low cost; meanwhile, it took in features of previous products, and can adapt galvanized steel sheet perfectly, almost can be applied to foundation coating of all metal, such as: cold and hot rolled steel sheet, galvanized steel sheet, aluminum products, zinc-aluminum alloy sheet and stainless steel sheet etc



This product features shown below : 





The bath has strong anti-shrinkage and anti-pollution ability





High throwing power, good internal and external uniformity





Low curing temperature, coating yellow degeneration resistance is good, suitable for electrodeposition primer, and then to spray or paint coating process, such as: oil heater, radiator, heater, lamps and lanterns, machinery, home appliances and hardware products and other industries







Main ingredients :



Neutralizing agent: organic acid



Additives: surface active agent, prevent shrinkage cavity agent,resistance to yellowing agent



Pigment: titanium dioxide, kaolin,antirust pigment



Solvent: alcohol ether



Matrix resin:acrylic modified epoxy resin



Curing agent: separation type fully enclosed isocyanate




The main supplier :



Material name Supplier
Bisphenol A epoxy resins Formosa Plastic Group / Kukdo / Dow Chemical
Polyisocyanates Bayer
Amine hardendner INTERSCAN / Huntsman Corporation



Bath on site management project :



Good bath data and coating quality, from the strict parameters management and maintenance of equipment, production line according to its own reality time situation, can have different management project and specifications, recommend the construction parameters see the table below for reference:





Classification Project Control Data Testing frequency
New bath Anolyte
Electrophoresis tank Ratio 1:(4-5) --
Ripening time 24-48 --
Solid ( 120 ℃ /1h ,% ) 12±2 -- once a day
PH 5.3-5.8 2.0-3.5 once a day
Conductivity ( μs/cm ) 900±400 1000±500 once a day
P/B 0.35-0.45 once a week
Solvent content (%) 1.2-2.0 once a week
Liquid level Fall head (cm ) 10-15 once a day
ED voltage( V ) 0-300 once a day
Break voltage ( V ) ≥350 once a week
Bath temperature ( ℃ ) 30±2 once a day
ED time( S ) 60~180 once a day
UF - 1 Tank Solid content (%) ≤2.0 once a day
UF - 2 Tank Solid content (%) ≤0.8 once a day
Baking furnace Provisions furnace temperature( ℃ ) 150-170 once a day
Curing conditions Drying temperature
(150-170)  ℃ x (15-20)min (With content holding time)
once a day



Construction equipment :



Cathodic electrophoretic coating construction in the electrophoresis tank, so need to have the following equipment: 

Electrophoresis tank 

Circulation devices (including filter, fill the paint device) 

DI water equipment 

DC power supply and the power supply unit 

Anode box (tube) and circulation device 

Ultrafiltration device 

Cleaning devices 

Heat exchanging equipment 

Curing device



If you want to learn more about HLS coating products, please contact Sales Department of Shanghai HLS now
