High Weatherability Black Cathode Edp Coating With Uv Radiation Resiistance

Good quality Cathodic Electrodeposition Paint for sales
Good quality Cathodic Electrodeposition Paint for sales
I'm Online Chat Now

High Weatherability Black Cathode Edp Coating With Uv Radiation Resiistance

China High Weatherability Black Cathode Edp Coating With Uv Radiation Resiistance supplier

Large Image :  High Weatherability Black Cathode Edp Coating With Uv Radiation Resiistance

Product Details:

Place of Origin: Shanghai China (Mainland)
Brand Name: HAOLISEN
Certification: IATF16949 , ISO9001
Model Number: HR-4000BLB/HR-6000

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: 50kg、60 kg、200kg、1000kg packaging barrels
Delivery Time: 30-60 Days
Supply Ability: 200 Tons Per Day
Contact Now
Detailed Product Description
Application Field: Ultraviolet Aging Main Ingredients: Totally Enclosed Multi-isocyanates
Performance: High Weatherability Cooperation Case: TORIN TOOLS

Black electrophoresis paint for the Motorcycle and the parts



Product Introduction :





HR-4000BLB/HR-6000 the bottom of one black cathode electrophoretic coating, is HLS Paint (Shanghai) Co., Ltd., the eighth generation of independent research and development of electrophoretic coating.





This coating by epoxy acrylate modified, the film also has excellent corrosion resistance and weatherability, smooth appearance and full, suitable as a base topcoat system. In addition, the lead, cadmium, chromium, mercury and other heavy metals, two-component, water dispersible resin, at the same time, previous generations of the product characteristics, have good adaptability to the galvanized steel, almost can be applied to all metal coating,



such as: cold hot rolled steel, galvanized steel, aluminum, zinc Aluminum Alloy plate, stainless steel plate.





This product features shown below: 



1,The appearance of the coating is flat, delicate, smooth. 



2,Good stability of bath can adaptable for a longer updating cycle.

etc



Main ingredients





Matrix resin: Acrylic modified epoxy resin



Curing agent: Fully enclosed multi isocyanate








Bath on site management project



Good bath data and coating quality, from the strict parameters management and maintenance of equipment, production line according to its own reality time situation, can have different management project and specifications, recommend the construction parameters see the table below for reference:



Classification Project Control Data Testing frequency
New bath Anolyte
Electrophoresis tank Ratio 1:(6-8) --
Ripening time 24-48 --
Solid ( 120 ℃ /1h ,% ) 15±5 -- once a day
PH 5.4-6.0 2.0-3.5 once a day
Conductivity ( μs/cm ) 1000±500 1400±900 once a day
P/B 0.08-0.15 once a week
L panel Smooth horizontal plane and vertical plane without obvious differences once a week
Solvent content (%) 0.5-1.8 once a week
Liquid level Fall head (cm ) 10-15 once a day
ED voltage( V ) 0-300 once a day
Break voltage ( V ) ≥350 once a week
Bath temperature ( ℃ ) 28-35 once a day
ED time( S ) 60~180 once a day
UF - 1 Tank Solid content (%) ≤2.0 once a day
UF - 2 Tank Solid content (%) ≤0.8 once a day
Baking furnace Provisions furnace temperature( ℃ ) 170-190 once a day
Curing conditions Drying temperature
(165-185)℃×(20-30)min (With content holding time)
once a day



Construction equipment:



Cathodic electrophoretic coating construction in the electrophoresis tank, so need to have the following equipment: 

Electrophoresis tank 

Circulation devices (including filter, fill the paint device) 

DI water equipment 

DC power supply and the power supply unit 

Anode box (tube) and circulation device 

Ultrafiltration device 

Cleaning devices 

Heat exchanging equipment 

Curing device
